Model: AC-BW60

Protocol:IEEE 802.3, 802.3u, 802.3ab

TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS, IPsec, PPTP, L2TP, CAPWAP Protocol

CPU: MT7621

DDR: 256M

Flash: 16M

Heat Dissipate: Natural heat dissipation

Ports: 4 × 10/100/1000Mbps LAN ports (can set to WAN port)

1 × 10/100/1000Mbps WAN port

Power: AC:100-240V,50HZ

Dimension: 277.8 180 37.7mm

Working Temperature: -20℃~55℃

Storage Temperature: -40℃~70℃

Working Humidity: 5% ~ 97%RH (No condensation)

Firmware features: AP Management

Max to access and manage 80 users

Max to manage60 PCS wireless AP

Centrally and remotely to manage/configure wireless AP

View user’s status

Smart Flow Control: One click smart flow control

Powerful multiline diversion

Application Priority Automatically

Load Balance: Multiple WAN, multiple ISP network access

Intelligence load balance

Ethernet line backup

Ethernet Superimposed

Policy routing: based on IP address, destination IP address, source MAC address, network port, domain, destination port, Extranet port, Identity binding

Protocol binding

Routing: Static Routing

Behavior Management: All-round to block P2P firmware

P2P flow control and bandwidth allot

File and URL filter

Monitor network behavior at all times

Bandwidth limitation: IP-based bandwidth limitation

Safeguard / Restrict bandwidth

Time strategy

IP based session restriction

Security Center: MAC address filter

UPR/key words filter

Web content filter

IP address filter

Port mapping

DMZ

Defense Center: TCP/UDP/ICMP flood defense

Block TCP scanning

Block ping WAN port

ARP Detection: Send GARP packets

ARP Scanning on WAN/LAN port

Online detection

IP-MAC binding

Authentication: PPPoE authentication. Portal authentication like Wechat Authentication, WEB password authentication, SMS authentication. IP and MAC authentication: Allow/deny user access by IP/MAC address

Management: Web/CLI/Telnet management

Remote management

Others: DDNS, VPN management
